Industrial Portable Dry Stream Generators

Dry Steam Generators

Oil Fired (Diesel/Kerosene)

Electric Motor

Portable

Dry steam generators are low water volume dry vapor steam cleaners perfect for thawing frozen drains, tanks, piping systems, and culverts. Their many industrial uses include curing cured-in-place (CIPP) liners during trenchless pipe and sewer repair. Trusted by street and highway departments and manufacturing plants alike, our dry steam machines are used for specialized tasks like thawing railroad tank cars and degassing fuel tanks for welding prep.

246EN
126

Dry Stream Generator Features

GPM = Gallons Per Minute     PSI =  Pressure Per Square Inch     V = Volt     PH = Phase     A = AMP

Flow Rate1 GPM
Pressure100 PSI
Operating Power50 to 80 psi
Motor Voltage115 v
Phase1
Horsepower1 hp
Fuel SourceKerosene, #1, #2 Diesel
Fuel Consumption5 gal/h
BTU Rating630,000 Btu
TemperatureUp to 300F Dry Steam
Pump StyleOil Bath Crankcase | Triplex Ceramic Plunger
Coil TypeSchedule 80
Steam TrapDry Steam Trap & Separator for removal of 85% of water
SafetySafety relief steam valve, low water, high temp, and high pressure safety
Controls
90 second Delay on Pump Shut Off 90 second Delay Timer on Burner Start Up Manual Reset High Limit Control Oil primary Control Pressure Gauge Pressure Switch Relief Valve Steam Separator Steam Trap Temperature Control Thermometer

WheelsTwo non-flat wheels & swivel casters for easy portability
Length87 in
Width42 in
Height42 in
Weight725 lbs
Flow Rate 1 gpm
Pressure 100 psi
Operating Power 80 to 100 psi
Motor Voltage 115 v
Phase 1
Horsepower 3/4 hp
Fuel Source Kerosene, #1, #2 Diesel
Fuel Consumption 3.5 gal/h
BTU Rating 460000 Btu
Pump Style Oil Bath Crankcase|Triplex Ceramic Plunger
Coil TypeSchedule 80
Controls
90 second Delay on Pump Shut Off 90 second Delay Timer on Burner Start Up Manual Reset High Limit Control Oil primary Control Pressure Gauge Pressure Switch Relief Valve Steam Separator Steam Trap Temperature Control Thermometer

Length34 in
Width28 in
Height43 in
Weight450 lbs

We're Here To Help

If you’re having trouble deciding what Alkota will work best for your needs, rest assured, we’re here to help! You can view additional models, find a local distributor, or drop us a line. We are looking forward to hearing from you!

Flat-Free Wheels and Casters

Belt drive tri-plex pump

Oil fired

630,000 BTU

115V Power Source

17 Gallon Fuel Tank
